Customized h6 Cemented Tungsten Carbide Bar High Strength For Cutting Tools

Customized h6 Cemented Tungsten Carbide Bar High Strength For Cutting Tools

Product Details:

Place of Origin: Zhuzhou,Hunan,China
Brand Name: Gingte Li
Certification: ISO9001:2015
Model Number: Φ10*40

Payment & Shipping Terms:

Minimum Order Quantity: 10KGs
Price: negotiable
Packaging Details: First paper packing each piece then pack into paper boxes or plastic box,next use exported cartons or wooden cases,or packed as
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 400 tons/year
Get Best Price Contact Now

Detail Information

Material: Contains 100% Virgin Tungsten And Cobalt Quality: High Strength High Hardness High Toughness
Service: 24-hour Online After-sale Service Technology: HIP Sintering And Adopt Advanced Automatic Extrusion Equipment
Size: Various Size And Grade For Choose Packaging: Standard Export Packing,or Per Customer Needs
Highlight:

tungsten carbide strips

,

tungsten carbide composite rods

Product Description

Customized Cemented Tungsten Carbide bar GF6X 10*40 high strength high hardness high toughness for cutting tool







 Product Advantages:

  1. No Pore Pressure Sintering
  2. High Strength High Hardness High Toughness
  3. Item Complete stock available
  4. factory direct sale customized size
  5. Well-trained sales can give you professional suggestions on product
  6. Small order is accepeted ,but not for free
  7. Our aim is to make every customer satisfied and we can be WIN-WIN

Application:

Rods Grade and performance for Cutting Tools



Grade



ISO Grade

WC% CO%



(µm)



g/cm3



HRA



HRC



HV



N/mm2



Applications Recommended

GF6X K10 94 6 0.8 14.9 91.5 78.4 1600 >3200 Suitable for steel cast iron,alloy cast iron , refractory steel ,alloy steel
GF8X K10-K20 92 8 0.8 14.7 90.5 77 1500 >3450 Suitable for glass firber reinforced plastics ,titanium etc and low speed cutting
GF10X K10-K20 90 10 0.8 14.4 90 75.9 1430 >3650 Suitable for cast iron ,non-ferrous metals,hard wood ,common wood etc
GF10A K30 88 10 0.6 14.4 91.8 79.3 1650 >3850 With hig temperature hardness, widely used in PCB micror drills .For making drills, end mill reamer , taps,burrs etc.
GF12A K40 86 12 0.6 14.2 91 77.7 1560 >4000 With high temperature hardness, for making drills ,end mill ,reamer ,taps , burrs etc.







Product Name Tungsten Carbide bar
Material cemented carbide
Size φ10*40 or others available
Size Tolerance h6 or as customer's request
Color As picture
Recommend Grade GF6X etc
Grain Size Medium Grain
Application for cutting tool
Processing Treatment Clean ground and polished or as customer request.
Product Features Long life,good wear resistance and high hardness.
Certification ISO9001







Grade Performances:

Carbide Rods Grades for Moulds

Grade ISO Grade WC % CO % Grain Size Density Hardness T.R.S Applications
(μm) g/cm3 HRA HRC HV N/mm²
GF8 K30 92 8 1.6 14.7 90 75.9 1400 ≥3500 Suitable for machining cast iron,aluminum alloy,quenched steels,brass etc,widely used in PCB micro drill and milling tools.
GF20 K40 80 20 1.2 13.7 84.5 66 900 ≥4200 High strength,mainly used for stamping tool can withstand great pressure.



Carbide Rods Grades for Cutting Tools

Grade ISO Grade WC % CO % Grain Size Density Hardness T.R.S Applications
(μm) g/cm3 HRA HRC HV N/mm²
GF6X K10 94 6 0.8 14.9 91.5 78.4 1600 ≥3200 Suitable for steel cast iron,alloy cast iron,refractory steel,alloy steel.
YL10.2 K30 88 10 0.6 14.4 91.5 79.3 1650 ≥3850 With high temperature hardness,widely used in PCB micro drills,for making drills,end mill,reamer,taps,burrs etc.



Size Options:

Type OD(MM) L(MM) Un-ground tolerance Fine ground tolerance
φ1~φ4×L 1~4 38.5 50 100 330 -0.00/+0.30 -0.00+L×1% h6
φ5~φ40×L 5~40 100 310 330 -0.00/+0.6

For any other sizes we are able to custom-made according to clients’ requirements or drawings.



Product Display and Advantages:



Tungsten Carbide Rods GF8 φ10*100 HRA90 for Milling Tools



Packing Process:

Tungsten Carbide Rods GF8 φ10*100 HRA90 for Milling Tools





FAQ



Q: Are you trading company or manufacturer ?

A: We are factory.



Q: How long is your delivery time?

A: Generally it is 3-5 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
