• Tungsten Carbide Roll Rings YG15 Grade
Tungsten Carbide Roll Rings YG15 Grade

Tungsten Carbide Roll Rings YG15 Grade

Product Details:

Place of Origin: Zhuzhou,Hunan,China
Brand Name: Gingte Li
Certification: ISO9001:2015
Model Number: 125*82*15 or others

Payment & Shipping Terms:

Minimum Order Quantity: 30KGs
Price: negotiable
Packaging Details: First paper packing each piece then pack into paper boxes,next use exported cartons or wooden cases,or packed as customers'requirement.
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 400 tons/year
Get Best Price Contact Now

Detail Information

Material: Tungsten Carbide Surface Treatment: Grinded
Applications: For High Speed Rolling Of Steel Bars Chemical Composition: WC+Cobalt
Roughness: 0.8 Or Others Shipping Terms: FOB,CIF,C&F Etc By Sea Or By Air
Sample: Available
High Light:

custom made tungsten carbide rings

,

tungsten carbide roll rings

,

Tungsten Carbide Roll Rings YG15

Product Description

Tungsten Carbide Roll Rings YG15 Grade

YG15 Tungsten Carbide Roll Rings for High Speed Rolling of Steel Bars

Product Descriptions :

Cemented carbide roller rings (also known as tungsten carbide roll rings), superior performance, quality and stability, high precision machining, good wear resistance and high impact resistance. The cemented carbide roller is a roll made ​​of tungsten carbide and cobalt material by powder metallurgy method. Cemented carbide roller integral and modular two kinds. It was in 1909, after the advent of powder metallurgy technology, with the development of the metal processing industry was born. Since 1918, Germany launched a cemented carbide drawing dies, inspired national cemented carbide, have appeared in a variety of uses roll. However, the cemented carbide roller a large number of applications in 1960. Morgan (Morgen) first high-speed twist-free wire rod mill was born in 1964, was the finishing speed of the wire increased 4 times. Since finishing mill work in the high-speed, high stress, poor wear resistance of cast iron roll, tool steel roller, rolling groove short life, roll repair handling very frequent, affecting the performance of the mill, were not suited to finishing production requirements, it is to be substituted by composition cemented carbide roller. The world has more than two hundred sets of Morgan mill, the consumption of hundreds of tons of cemented carbide roller.

We Gingte mainly offer tungsten carbide rings blanks,round shape or with chamfer, or according to customer's drawing and prints to make, not only sintered one but also we can process the outer diameter, inner hole and two faces,so warmly welcone to contact us at your free time : )





Product Specifications:

1. Product Name: Cemented Carbide Rings

2. Material: Cemented Carbide

3. Size: 125*82*15

4. Size Tolerance: free tolerance or as customer's request

5. Shape: Round Shape with chamfer

6. Recommend Grade: YG15 etc

7. Grain Size: Medium Grain

8. Applications: for steel bars

9. Sintering Treatment: HIP sintering

10. Product Features: Long life, superior performance

11. Certification: ISO9001



Grade Performance:

Tungsten Carbide Rings
Grades Density T.R.S Hardness Performance & application recommended
g/cm³ MPa HRA

YG6X

14.9

≥3200

91.5

A fine grain grade with better wear resistance and good strength,qualified for machining of child cast iron,alloy cast iron,refractroy steel and alloy steel ,also for finishing of normal cast irons etc.

YG10X

14.4

≥3650

90

Suitable for cast iron, non-ferrous metals etc.

YG11

14.4

≥3000

88.5

Forming or stamping dies for metal powders and nonmetal powders.

YG15

14

≥3400

87.5

For fabricating drawing dies of steel tubes and rods under High compressibility ratio; punching, stamping, forging tools under large stress.

YG16C

13.9

≥3500

85.5

Cold rolling of ribbed steel bars







Size Options:



Outer Diameter
(mm)
Inner Diameter
(mm)
Thickness
(mm)
φ50~φ318 φ3~φ280 5~100

For any other sizes we are able to custom-made according to clients’ requirements or drawings.





Quality assurance:

  • Every production process has a special person to test to ensure quality

  • Have professional engineers to check the quality

  • All products are under strict quality system management based on ISO9001:2008





Packing Process:

Tungsten Carbide Roll Rings YG15 Grade 0





FAQ



Q: Are you trading company or manufacturer ?

A: We are factory.



Q: How can i place an order ?
A: Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
For designing or further discussion, it is better to contact us with Skype / email / phone, in case of any delays.



Q: What is your terms of delivery ?
A: We accept EXW, FOB, C&F, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.



Q: How long is your delivery time ?

A: Generally it is 3-5 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.







Contact us at your free time when you are interested in our products : )
