Wear Resistance Tungsten Carbide Bar / Cemented Carbide Round Bar For Dies Rods

Wear Resistance Tungsten Carbide Bar / Cemented Carbide Round Bar For Dies Rods

Product Details:

Place of Origin: Zhuzhou,Hunan,China
Brand Name: Gingte Li
Certification: ISO9001:2015
Model Number: K30 20*60

Payment & Shipping Terms:

Minimum Order Quantity: 10KGs
Price: negotiable
Packaging Details: First paper packing each piece then pack into paper boxes or plastic box,next use exported cartons or wooden cases,or packed as
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 400 tons/year
Get Best Price Contact Now

Detail Information

Material: 100% Virgin Tungsten And Cobalt Quality: Long Life With Super Resistance To Heat Wear And Abrasion
Size: Various Size And Grade To Choose For Customer Technology: No Pore Pressure Sintering
Shipments: Fast Delivery In 7 To 15 Days Service: 24-hour Online After-sale Service
High Light:

tungsten carbide strips

,

solid carbide rod

Product Description

Wear Resistance Tungsten Carbide Bar / Cemented Carbide Round Bar For Dies Rods


Tungsten Carbide round rod K30 20*60 high strength high hardness high toughness for dies rods




Detailed Product Description:


Cemented Tungsten carbide rod has many excellent characteristics ,such as high hardness and strengh, good corrosion resistance and salient stability under high temperature.Adopt advanced automatic extrusion equipment to produce .HIP sintering and precision grinding to ensure have good performance ,both blank and finished available ,product can reach a mirror effect surface after accurate grinding and polishing.



Feastures:

  • No Pore Pressure Sintering
  • High Strength High Hardness High Toughness
  • Item Complete
  • Stock Available

Application:



High puring tungsten rods can be used as heat conductor additive , crankshaft and cylinder barrel of automobile,part of heat-resistant steel and electrode.High purity tungsten rods are mainly used in guns ,rockets , satellites, airplanes and ships.





Product Name Tungsten Carbide Rod
Material cemented carbide
Size φ20*60 or others available
Size Tolerance h6 or as customer's request
Color As picture
Recommend Grade  K30 etc
Grain Size Medium Grain
Application used in guns ,rockets , satellites, airplanes and ships
Processing Treatment Clean ground and polished or as customer request.
Product Features Long life,good wear resistance and high hardness.
Certification ISO9001







Grade Performances:

Carbide Rods Grades for Moulds

Grade ISO Grade WC % CO % Grain Size Density Hardness T.R.S Applications
(μm) g/cm3 HRA HRC HV N/mm²
GF8 K30 92 8 1.6 14.7 90 75.9 1400 ≥3500 Suitable for machining cast iron,aluminum alloy,quenched steels,brass etc,widely used in PCB micro drill and milling tools.
GF20 K40 80 20 1.2 13.7 84.5 66 900 ≥4200 High strength,mainly used for stamping tool can withstand great pressure.



Carbide Rods Grades for Cutting Tools

Grade ISO Grade WC % CO % Grain Size Density Hardness T.R.S Applications
(μm) g/cm3 HRA HRC HV N/mm²
GF6X K10 94 6 0.8 14.9 91.5 78.4 1600 ≥3200 Suitable for steel cast iron,alloy cast iron,refractory steel,alloy steel.
YL10.2 K30 88 10 0.6 14.4 91.5 79.3 1650 ≥3850 With high temperature hardness,widely used in PCB micro drills,for making drills,end mill,reamer,taps,burrs etc.



Size Options:

Type OD(MM) L(MM) Un-ground tolerance Fine ground tolerance
φ1~φ4×L 1~4 38.5 50 100 330 -0.00/+0.30 -0.00+L×1% h6
φ5~φ40×L 5~40 100 310 330 -0.00/+0.6

For any other sizes we are able to custom-made according to clients’ requirements or drawings.



Product  Application:



Tungsten Carbide Rods GF8 φ10*100 HRA90 for Milling Tools



Packing Process:

Tungsten Carbide Rods GF8 φ10*100 HRA90 for Milling Tools





FAQ:



Q: Are you trading company or manufacturer ?

A: We are factory.



Q: How long is your delivery time?

A: Generally it is 3-5 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
