Impact Resistance YG23C Colding Head Tungsten Carbide Pellets For Nuts And Screws
Product Details:
| Place of Origin: | Zhuzhou,Hunan,China |
| Brand Name: | ZZGT Li |
| Certification: | ISO9001:2015 |
| Model Number: | customized |
Payment & Shipping Terms:
| Minimum Order Quantity: | Samples are accepted |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Paper box , Wooden Carton or Customized accepted |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C, D/A, T/T, Western Union, MoneyGram |
| Supply Ability: | 400T/year |
|
Detail Information |
|||
| Grade: | YG23C,YG20C | Material: | Tungsten Carbide With Cobalt |
|---|---|---|---|
| ISO: | K30 | Finished: | Supported |
| Size: | As Customer Requirement | Application: | Colding Head |
| Advantage: | Durable | ||
| High Light: | cold forging die,tungsten carbide heading die |
||
Product Description
Impact resistance YG23C tungsten carbide colding head Pellets for Nuts and Screws
About Company:
Heading application heading pellets are widely used in fastener industries. The very high compressive strength like wear resistance, edge retention and ability to operate at high temperature. These pellets are used in hot and cold forging dies,special extrusion dies and nut forming dies.
Various Sizes for Options
| Type | OD | ID | H | Tolerance | ||
| OD | Id | H | ||||
| D10~14×φd | 10~14 | 1.0～5.0 | 15～40 | D×+3% | d×-3% | H×+3% |
| D15~24×φd | 15~24 | 1.5～8.0 | 20～60 | |||
| D25~40×φd | 25~40 | 1.5～25 | 30～60 | |||
| D42~95×φd | 42~95 | 2.0～50 | 20～95 | |||
For any other sizes we are able to custom-made according to clients’ requirements or drawings
Grade Performance
| Tungsten Carbide Cold Forging/heading Dies | |||||
| Grades | Density | T.R.S | Hardness | Performance & application recommended | |
| g/cm³ | MPa | HRA | |||
| YG11 | 14.4 | ≥3000 | 88.5 | Forming or stamping dies for metal powders and nonmetal powders. | |
| YG15 | 14 | ≥3400 | 87.5 | For fabricating drawing dies of steel tubes and rods under High compressibility ratio; punching, stamping, forging tools under large stress. | |
| YG20 | 13.5 | ≥3800 | 85.5 | For fabricating of stamping dies for watch parts, spring plates of musical instruments, battery jars, small sized steel balls, screws, screw caps. | |
| YG15C | 14 | ≥4000 | 86.5 | For oil cone drill bits,cut medium soft and hard rocks;debarking and cutting of frozen wood,soft wood and original wood. | |
| YG16C | 13.9 | ≥3500 | 85.5 | Impact resistance forging dies. | |
| YG18C | 13.7 | ≥3600 | 84.5 | Impact resistance forging dies, hot-press forging dies and rollers. | |
| YG20C | 13.5 | ≥3800 | 83.5 | Dies for wear resistant or impact resistant application. | |
| YG22C | 13.3 | ≥4000 | 83 | Nut forming dies and high impact resistance forging dies. | |
| GT55 | 13.1 | ≥4250 | 82.5 | Stainless bolt header dies and rollers. | |
More Details:
• Dependable cemented carbide with fracture toughnesses for heading and nut forming
• Long wearing cemented carbide grades that meet industry requirements for extrusion applications
• Higher yields resulting from Hyperion's quality cemented carbides
• Higher output with tailor-made tolerance options.
Factory Equipments:
There are some advanced producing equipments in Zhuzhou Gingte Cemented Carbide Co.,ltd
*HIP sintering furnace
*Spraying Draying system
*200T TPA acutomatic press machine
*CNC Grinder
*Spark Erosion machine
*Wire cutting machine,etc
