Cemented Carbide Cold Heading Dies Wear Resistance And Corrosion Resistance
Product Details:
| Place of Origin: | Zhuzhou city, Hunan province, China |
| Brand Name: | Gingte |
| Certification: | ISO9001:2015 |
| Model Number: | Various types |
Payment & Shipping Terms:
| Minimum Order Quantity: | 20 Kilograms |
|---|---|
| Price: | negotiable |
| Packaging Details: | Standard export packing or packed as customers' requirement. |
| Delivery Time: | 7-25 days once get the deposit |
| Payment Terms: | L/C, T/T , Western Union, MoneyGram, E-Checking |
| Supply Ability: | 400 tons/year |
|
Detail Information |
|||
| Product Name: | Cemented Carbide Unground Puching Die | Material: | Tungsten Carbide /cemented Carbide |
|---|---|---|---|
| Surface Treatment: | Unground/ Blanks | Price: | Competitive |
| Application: | For Fastener Indurstry | Size: | Size Complete |
| High Light: | cold forging die,tungsten carbide heading die |
||
Product Description
Cemented Carbide Cold Heading Dies Wear Resistance And Corrosion Resistance
Wear resistance and corrosion resistance cemented carbide cold heading dies
Product advantages:
- High hardness
- Corrosion resisance
- High pressure resistance
- Quality stability
- High cost performance
- Various Grades for choice
- Various sizes for option
- Customization is acceptable
Product Description:
Carbide Screw Header Punches Die area is one of the main applications of tungsten carbide material. Heading dies usually can be divided into punching die and bushing die , used in cold heading, warm heading and hot heading technology situation.
About us:
Zhuzhou Gingte cemented carbide Co.;Ltd is a professional factory of tungsten carbide with rich experience in this industry .
At present, the company developed various types of products including carbide rods, plates, cold heading dies , blades and so on. Especially the tungsten carbide rods, it is most popular product in the market due to its high quality and reasonalble price .
If you have any questions or requirements for tungsten carbide products, you do no hezitation to contact us, I am sure there is one product can be matched you.
Quality assurance:
-
Every production process has a special person to test to ensure quality
-
Have professional engineers to check the quality
-
All products are under strict quality system management based on ISO9001:2015
Grade Performance:
| Tungsten Carbide Cold Forging/heading Dies | ||||
| Grades | Density | T.R.S | Hardness | Performance & application recommended |
| g/cm³ | MPa | HRA | ||
| YG11 | 14.4 | ≥3000 | 88.5 | Forming or stamping dies for metal powders and nonmetal powders. |
| YG15 | 14 | ≥3400 | 87.5 | For fabricating drawing dies of steel tubes and rods under High compressibility ratio; punching, stamping, forging tools under large stress. |
| YG20 | 13.5 | ≥3800 | 85.5 | For fabricating of stamping dies for watch parts, spring plates of musical instruments, battery jars, small sized steel balls, screws, screw caps. |
| YG15C | 14 | ≥4000 | 86.5 | For oil cone drill bits, cut medium soft and hard rocks; debarking and cutting of frozen wood, soft wood and original wood. |
| YG16C | 13.9 | ≥3500 | 85.5 | Impact resistance forging dies. |
| YG18C | 13.7 | ≥3600 | 84.5 | Impact resistance forging dies, hot-press forging dies and rollers. |
| YG20C | 13.5 | ≥3800 | 83.5 | Dies for wear resistant or impact resistant application. |
| YG22C | 13.3 | ≥4000 | 83 | Nut forming dies and high impact resistance forging dies. |
| YG25C | 13.1 | ≥4250 | 82.5 | Stainless bolt header dies and rollers. |
Sizes for option:
| Type | OD | ID | H | Tolerance | ||
| OD | ID | H | ||||
| φD10~14×φd | 10~14 | 1.0～5.0 | 15～40 |
D×+3% |
d×-3% |
H×+3% |
| φD15~24×φd | 15~24 | 1.5～8.0 | 20～60 | |||
| φD25~40×φd | 25~40 | 1.5～25 | 30～60 | |||
| φD42~95×φd | 42~95 | 2.0～50 | 20～95 | |||
For any other sizes we are able to custom-made according to clients’ requirements or drawings.
Package:
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.
Q: How long can I expect to get the sample?
A: After you pay the sample charge and send us confirmed files, the samples will be ready for delivery in 3-7 days. The samples will be sent to you via express and arrive in 3-5 workdays. You can use your own express account or prepay us if you do not have an account.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Q: Can I have a visit to your factory before the order?
A: Sure, welcome your visit of factory.
