Grinded Surface Tungsten Steel Rings HIP Sintering Type For Hot Rolling
Product Details:
| Place of Origin: | Zhuzhou,Hunan,China |
| Brand Name: | Gingte Li |
| Certification: | ISO9001:2015 |
| Model Number: | 75*63*30 or others |
Payment & Shipping Terms:
| Minimum Order Quantity: | 30KGs |
|---|---|
| Price: | negotiable |
| Packaging Details: | First paper packing each piece then pack into paper boxes,next use exported cartons or wooden cases,or packed as customers'requirement. |
| Delivery Time: | 7-15 work days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 400 tons/year |
|
Detail Information |
|||
| Material: | Tungsten Steel | Surface Treatment: | Clean Ground |
|---|---|---|---|
| Applications: | For Hot Rolling | Chemical Composition: | WC+Cobalt |
| Roughness: | 0.8 Or Others | Shipping Terms: | FOB,CIF,C&F Etc By Sea Or By Air |
| Sample: | Available | ||
| High Light: | custom tungsten carbide rings,custom made tungsten carbide rings |
||
Product Description
Grinded Surface Tungsten Steel Rings HIP Sintering Type For Hot Rolling
YG15 grade Grinded Surface Tungsten Steel Rings for Hot Rolling
Product Features :
As compared with conventional tungsten steel roll rings, the new generation of roll rings for high speed rolling of steel bars have a higher resistance to impact and thermal fatigue and a very high wear resistance as well.
The outstanding characteristics of cemented carbide roll rings that are different from conventional cemented carbide roll rings in practical applications are as follows:
They are suitable for high speed bar rolling machines with a speed of above 100m/s,and it is not easy for them to result in cracks, breakage, groove aging and chips.
They can be used for rolling conventional steel bars, but also for high speed rolling of alloy steel bars.
There is a high volume of steel rolled per groove and little regrinding of the groove is needed after the rolling is finished.
They can be used for the rolling of conventional steel bars and alloy steel bars at a high speed and low temperatures.
Product Specifications:
1. Product Name: Tungsten Steel Rings
2. Material: Tungsten Steel
3. Size: 75*63*30
4. Size Tolerance: free tolerance or as customer's request
5. Shape: Round Shape with hole
6. Recommend Grade: YG16C etc
7. Grain Size: Medium Grain
8. Applications: for hot rolling
9. Sintering Treatment: HIP sintering
10. Product Features: Long life, superior performance
11. Certification: ISO9001
Grade Performance:
| Tungsten Carbide Rings | |||||
| Grades | Density | T.R.S | Hardness | Performance & application recommended | |
| g/cm³ | MPa | HRA | |||
|
YG6X |
14.9 |
≥3200 |
91.5 |
A fine grain grade with better wear resistance and good strength,qualified for machining of child cast iron,alloy cast iron,refractroy steel and alloy steel ,also for finishing of normal cast irons etc. |
|
|
YG10X |
14.4 |
≥3650 |
90 |
Suitable for cast iron, non-ferrous metals etc. |
|
|
YG11 |
14.4 |
≥3000 |
88.5 |
Forming or stamping dies for metal powders and nonmetal powders. |
|
|
YG15 |
14 |
≥3400 |
87.5 |
Cold rolling of ribbed steel bars. |
|
|
YG16C |
13.9 |
≥3500 |
85.5 |
Impact resistance forging dies,hot rolling etc. |
|
Size Options:
| Outer Diameter (mm) |
Inner Diameter (mm) |
Thickness (mm) |
| φ50~φ318 | φ3~φ280 | 5~100 |
| … | … | … |
For any other sizes we are able to custom-made according to clients’ requirements or drawings.
Quality assurance:
-
Every production process has a special person to test to ensure quality
-
Have professional engineers to check the quality
-
All products are under strict quality system management based on ISO9001:2008
Packing Process:
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How can i place an order ?
A: Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time.
For designing or further discussion, it is better to contact us with Skype / email / phone, in case of any delays.
Q: What is your terms of delivery ?
A: We accept EXW, FOB, C&F, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.
Q: How long is your delivery time ?
A: Generally it is 3-5 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
Contact us at your free time when you are interested in our products : )
