• K40 10*100 Tungsten Carbide Bar , No Pore Pressure Sintering Tungsten Carbide Rod
  • K40 10*100 Tungsten Carbide Bar , No Pore Pressure Sintering Tungsten Carbide Rod
K40 10*100 Tungsten Carbide Bar , No Pore Pressure Sintering Tungsten Carbide Rod

K40 10*100 Tungsten Carbide Bar , No Pore Pressure Sintering Tungsten Carbide Rod

Product Details:

Place of Origin: Zhuzhou,Hunan,China
Brand Name: Gingte Li
Certification: ISO9001:2015
Model Number: 10*100

Payment & Shipping Terms:

Minimum Order Quantity: 10KGs
Price: negotiable
Packaging Details: First paper packing each piece then pack into paper boxes or plastic box,next use exported cartons or wooden cases,or packed as
Delivery Time: 7-15 work days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 400 tons/year
Get Best Price Contact Now

Detail Information

Material: 100% Virgin Tungsten And Cobalt Size: Can Design The Best Grade According To Its Applications
Service: 24-hour Online After-sale Service Quality: High Hardness High Strength High Toughness
Technology: Imported Equipment HIP Sinter Packaging: Convenient Packaging With Standard Export Packing Or According The Needs Of Customer's
High Light:

cemented carbide rods

,

tungsten carbide bar

Product Description

Cemented Tungsten Carbide Rods K40 10*100 no pore pressure sintering for Dies rods







Product Advantages:

  • No Pore Pressure Sintering
  • Material contains 100% virgin tungsten and cobalt
  • High Strength High Hardness High Toughness
  • Item Complete stock available
  • factory direct sale customized size
  • Well-trained sales can give you professional suggestions on product
  • Small order is accepeted ,but not for free
  • Our aim is to make every customer satisfied and we can be WIN-WIN





Product Feature:



Cemented Tungsten carbidei is a sintered metallurgical product of powder form.Cemented Tungsten carbide rod has many excellent characteristics such as high hardness and strength ,good corrossion resistance and salient stability under high temperature.It can be used to cut cast iron ,non-ferrous metals, plastics , chemical fiber,stainless steel and high manganese steel ,etc.,and make drilling tools ,mining tools ,wear parts, precision bearings ,nozzles and metal, molds,etc.






Product Name Tungsten Carbide rods
Material cemented carbide
Size φ10*100 or others available
Size Tolerance h6 or as customer's request
Color As picture
Recommend Grade  K40 etc
Grain Size Medium Grain
Application for Dies rods
Processing Treatment Clean ground and polished or as customer request.
Product Features Long life,good wear resistance and high hardness.
Certification ISO9001







Grade Performances:

Carbide Rods Grades for Moulds

Grade ISO Grade WC % CO % Grain Size Density Hardness T.R.S Applications
(μm) g/cm3 HRA HRC HV N/mm²
GF8 K30 92 8 1.6 14.7 90 75.9 1400 ≥3500 Suitable for machining cast iron,aluminum alloy,quenched steels,brass etc,widely used in PCB micro drill and milling tools.
GF20 K40 80 20 1.2 13.7 84.5 66 900 ≥4200 High strength,mainly used for stamping tool can withstand great pressure.



Carbide Rods Grades for Cutting Tools

Grade ISO Grade WC % CO % Grain Size Density Hardness T.R.S Applications
(μm) g/cm3 HRA HRC HV N/mm²
GF6X K10 94 6 0.8 14.9 91.5 78.4 1600 ≥3200 Suitable for steel cast iron,alloy cast iron,refractory steel,alloy steel.
YL10.2 K30 88 10 0.6 14.4 91.5 79.3 1650 ≥3850 With high temperature hardness,widely used in PCB micro drills,for making drills,end mill,reamer,taps,burrs etc.



Size Options:

Type OD(MM) L(MM) Un-ground tolerance Fine ground tolerance
φ1~φ4×L 1~4 38.5 50 100 330 -0.00/+0.30 -0.00+L×1% h6
φ5~φ40×L 5~40 100 310 330 -0.00/+0.6

For any other sizes we are able to custom-made according to clients’ requirements or drawings.



Product Display and Advantages:



Tungsten Carbide Rods GF8 φ10*100 HRA90 for Milling Tools



Packing Process:

Tungsten Carbide Rods GF8 φ10*100 HRA90 for Milling Tools





FAQ



Q: Are you trading company or manufacturer ?

A: We are factory.



Q: How long is your delivery time?

A: Generally it is 3-5 days if the goods are in stock. or it is 15-25 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples ? is it free or extra ?

A: Yes, we could offer the sample for free charge but do not pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
